About Trail Ridge:
Trail Ridge Truck Accessories are developed and built with a promise to provide high quality, durable parts for your truck; backed by the best warranty in the automotive industry. Manufactured from the highest quality materials and constructed to meet or exceed OEM standards. Every Trail Ridge part is rigorously tested ensuring superior fit, function, and durability. Quality, trusted value, and hassle-free installation backed by our 100% satisfaction guarantee.
Exact fit - To obtain proper fit and function confirm your vehicle has the exact mirror options listed.
Attention California Customers:
WARNING: This product can expose you to chemicals including Chromium (Hexavalent Compounds), which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov
Lifetime Warranty
This item is backed by our limited lifetime warranty. In the event that this item should fail due to manufacturing defects during intended use, we will replace the part free of charge. This warranty covers the cost of the part only.
FREE Shipping is standard on orders shipped to the lower 48 States (Contiguous United States). Standard shipping charges apply to Hawaii and Alaska.
Shipping is not available to a P.O. Box, APO/FPO/DPO addresses, US Territories, or Canada for this item.
Expedited is available on checkout to the United States, excluding Alaska, Hawaii.
Final shipping costs are available at checkout.
Created on:
Tools used
Hi, I’m Mike from 1A Auto. We’ve been selling auto parts for over 30 years!
To remove the master window switch we'll use a plastic prying tool. You can get this from 1A Auto. This way we don't damage the trim. Gently slide it up in here and help pop it up off the clips. There's a clip on this side, so I'm going to work it in. So you're basically just trying to pull it straight up off of these white clips here and then these clips here that push into the door panel. The lock on the connector is here. Push that in and pull the connector out. Use my plastic trim tool to help me. It’s kind of a small clip, so I'm going to push it in and take it off.
Now remove the small trim that's on top of the door panel. Use the plastic trim tool again. Get underneath here, and gently pry it off. You can almost access the mirror. We'll take the rest of the door panel off. Screw behind the door pull handle. There's a plastic trim that's covering it. Again, use the plastic trim tool, go in here, and pop this out. There's four clips. It pops right out. Use a Philip's head screwdriver and remove the screw. Inside the door pull handle there's this little felt pad, lift that up and get it out of here and there's a Philips head screwdriver sitting right in the bottom there and that needs to be removed.
To remove this push clip, actually take a small flap bladed screwdriver. You push in on it and that unlocks it. Then I'm going to use the plastic trim tool to pop it up and out. The door panel should now just be clipped in place with those screws removed. There's clips along the outside edge. To take them off, you're going to have to start usually at the bottom of the door because the top of the door rolls over the sheet metal. Give it a good pull to try to separate it. Then lift it up. Door cables for the lock and pull handle are connected, so this top one is the lock, so it's a white cable. I'm going to push it up to unlock it, and then move it over and slide that little lead ball out of there. The green one is for the door pull handle, so pop that up and out and then pull these out. These are called Bowden cables. And we put the door panel aside.
Unplug the mirror harness. Push up on the lock. It's on the bottom. Pull the connector right out. To unbolt the mirror, there's three studs with 10-millimeter nuts on them. Use a 10-millimeter socket extension ratchet to loosen them all up. The mirror is clipped in place. Take the mirror off. So it is clipped in there, so right here. So I'm just going to give it a good tug here.
Here's our upgraded Trail Ridge towing mirrors we have for the vehicle. So these are slightly larger with a manual extension for towing, and then you'll just push them back in. Flip them over. These particular ones have blind spot monitoring included and heated and power. They also have the extra mirror at the bottom that is manually adjusted to where you want it to be. It will stay that way. These ones will adjust with the power. Then the outside, this one has the smoked turn signal and marker light bulb. These particular ones are plug-and-play. These will work great and fit great on your vehicle.
Going to install the Trail Ridge. These are plug-and-play tow mirrors. They'll install just like the original. Put the studs through the openings in the door. I'm going to hold it because it doesn't have a clip. It does help to have the window down so you can go through. Got one of the nuts ready to go. I'll get it caught on the stud here that's easy to access. I'll just thread it down with my fingers so the mirror doesn't fall off the door. There. The other nuts caught. Just tightening down. I don't want to pull the studs out of the mirror. Once I feel them get tight, I'll stop. Do the same for the other two. Finally, plug it back in.
To reinstall your door panel, this will be the same for both sides. Hook up the white Bowden cable goes in the top for the lock. Pull the ball through here, clip it in place. The green one is for the door handle, same way, put it in, clip it in place. Top of the door panel has a hook to it. It will hang on the sheet metal. Get it started up top first, push it down. Clips will push into place. Make sure that your wire is accessible for your master window switch. Little plastic push clip, after you've pushed it in you can push it back out and reuse it, go right in and lock in place. Reinstall the screw here. Reinstall the one on the door handle. Put this trim back in place. It’s got some clips, open up the door handle, line it up and snap into place. Put your little felt pad back in there. Triangle piece back on, just push into place. Master window switch, plug it in, push it in, and it locks. Then the door panel snaps into place.
Thanks for watching. Visit us at 1AAuto.com for quality auto parts, fast and free shipping, and the best customer service in the industry.
TR00073
Worked great for a year or so then the driver side blinker started to go out randomly. It use to work when we went over bumps but now its out completely. Not happy they didnt last for the cost.
Very satisfied with the mirrors for my Tundra, perfect fit and easy installation. so easy and plug and play, everything worked right out of the box
I thought it would be a little bit better quality. The mirror is shake a lot while you're driving.
I really like the mirrors. They don't have that annoying shake that you see on some tow mirrors. Great value and easy to install.
After using these mirrors for about 2 months now I can tell you that these mirrors are very good. I love the BSM and defrost features and running lights and blinker, it hasn't been cold enough to test the defrost function yet although I don't have any doubts that it will work well. I had one question and customer service was very fast and friendly .
Worked out as it should have. Easy to order Arrived on time Very good quality Easy installation with video provided Could not be happier with 1A Auto
1AAuto also come through with best customer service and all the parts. Very very please with all my orders purchased. Also on time I recommend 1AAuto parts to every one I know thanks again
Very good quality. already bumped into a couple objects and they are sturdy
I've had these mirrors installed for about 2.5 years and they have been great, no issues whatsoever...until yesterday. The drivers side blinker is no longer working all of a sudden. Blinker working on headland tail lights. Is this a bulb issue? Any way to fix this without getting a whole new mirror assembly?
All I can say is I love it Just like the product Says plug and play Works great looks great So easy to put in thanks for making it.
Mirrors should be replaced in an "option for option" fashion. If your mirrors do not have the same options that are listed in our listing, there is a possibility that this mirror may not function properly.
Only side to side. Might be able to adjust a couple of mm but no more. I find the view from the bottom mirror to be right on for all driving conditions.
Hello, I apologize we do not have the OEM part number, however, these are listed to fit 2014-2020 Toyota Tundra with the options Driver & Passenger Side Power Heated Smoked Lens Turn Signal & Clearance Light Blind Spot Detection Manual-Folding Textured Black Manual-Telescoping. Mirrors should be replaced in an "option for option" fashion. If your mirrors do not have the same options that are listed in our listing, there is a possibility that this mirror may not function properly.
This part will not fit your vehicle, but we may have a part that is listed to fit. Please enter your vehicle's year make and model in the search bar at the top of the page. This will display parts guaranteed to fit your vehicle. Just be sure to verify all of the information shown in the Vehicle Fit tab before ordering.
Currently, we do not carry this part for your vehicle. We're always updating our inventory so please check back soon!
Hello, I am sorry to hear you are having a problem with the telescoping I have emailed you directly for a resolution.
The lower glass on both mirrors are convex, but the upper glass is not.
Mirrors should be replaced in an "option for option" fashion. If your mirrors do not have the same options that are listed in our listing, there is a possibility that this mirror may not function properly.
They should be compatible. The Limited doesn't have turn signal and clearance lights on the mirrors, but the wiring harness has the circuits so those features will work with these mirrors
There could be multiple reasons why you're having this particular problem. We suggest taking your vehicle to a nearby reputable shop to identify the cause. Once you know the cause, we'll be happy to see if we carry the parts and how-to videos needed for your repair.
