TRQ ignition coils will have your engine running like new. TRQ ignition coils are manufactured to precise specifications using premium raw materials to optimize each vehicle's ignition system. To ensure peak performance, TRQ recommends replacing ignition coils in sets to prevent electrical output imbalances. All products are fit and road-tested in our Massachusetts R&D facility to ensure we deliver on our promise of Trusted Reliable Quality.
Returns: Parts with electrical components cannot be returned once installed.
Attention California Customers:
WARNING: This product can expose you to chemicals including Lead and Lead Compounds, which are known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Lifetime Warranty
This item is backed by our limited lifetime warranty. In the event that this item should fail due to manufacturing defects during intended use, we will replace the part free of charge. This warranty covers the cost of the part only.
Returns: Parts with electrical components cannot be returned once installed.
FREE Shipping is standard on Orders shipped to the lower 48 States (Contiguous United States). Standard shipping charges apply to Hawaii, Alaska and US Territories. Shipping is not available to Canada.
Expedited is available on checkout to the United States, excluding Alaska, Hawaii and US Territories as well as P.O. Boxes and APO/FPO/DPO addresses. Final shipping costs are available at checkout.
Created on:
Tools used
Hi, I’m Mike from 1A Auto. We’ve been selling auto parts for over 30 years!
Open the hood. We have to pull the release inside the car. It's just inside right around your left knee on the driver's side. Need to release the secondary, or safety release. Just kind of feel around for it. This one is right here. Squeeze up.
Going to remove these two top nuts that hold on the appearance cover. They are 10 millimeter, so I'm using a 10 millimeter socket ratchet and extension. Should just thread of real easily. So there's our appearance cover, it's got some foam inside. That's just for noise, just keeps the noise down from the valve train.
Here are your four coil packs. One for each cylinder. They're held in to the valve cover with a 10 millimeter bolt, one for each. Push down on the lock and remove the connector. These can be brittle, sometimes they break. The lock does. This procedure will be the same for the other three. Use a ratchet, extension, and 10 millimeter socket to remove this 10 millimeter bolt. Put this bolt aside.
Now we need to remove the coil. Might have to wiggle it because there is a seal in here and just break it free. Once it's free, it should come right up. There's our coil pack.
It does have some oil on it because our valves cover gasket has been leaking. Reinstall the coil. Line up the opening with the amounting bolt hole. Move the harness out of the way so it doesn't get pinched. Push right over the spark plug and reinstall the bolt. Once it gets tight I'm just going to stop. Put the connector back in.
Now I can reinstall the plastic engine cover. I wiped it down with a rag and cleaned some of the dirt off of it. Make it look a little nicer. Get lined up over those studs. Sit right down reinstall the nuts. Actually just do these hand tight. They don't need to be super tight. Job is complete.
Thanks for watching. Visit us at 1AAuto.com for quality auto parts, fast and free shipping, and the best customer service in the industry.
