How to Remove Wiper Arms 2003-07 Cadillac CTS
Created on: 2016-08-09
Watch this video to learn how to replace bent or broken wiper arms. The experts at 1A Auto show you how to replace the wiper arms on your 05-06 Cadillac CTS.
-
step 1 :Removing the Wiper Arms
- Remove the black caps from the bottom of the wiper arms
- Insert painter's tape to mark the position and angle of the wiper blade
- Remove the two 15mm nuts from the wiper arms
- Push the wiper arm in and out until it works off the splines
-
step 2 :Installing the Wiper Arms
- Press the wiper arm into place, aligning it with the tape
- Tighten the 15mm nut to the arm
- Torque the nut to 26 foot-pounds
- Put the cap back on
- Test the wipers for functionality
Tools needed
-
Ratchet
Torque Wrench
15mm Socket
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to remove your cowl cover, or air grille, on this 2006 Cadillac CTS. Here are the items you'll need for this repair: 15mm socket and ratchet.
Remove the black caps on the windshield wiper arms. All you have to do is squeeze them together and pop them off. We're going to use a small piece of painter’s tape. Sure you use the straight edge to mark the position and angle of the wiper blade so we can reinstall our wiper arms properly. Remove the two 15 millimeter nuts securing the wiper arms down with a the 15 millimeter sock and ratchet. If you're only replacing one arm, you'll only have to do this for that particular one. Work the wiper arms off of the splines. Do this by grabbing them at the joint. Simply pulling up and pushing down. Eventually, it'll work its way off the splines, and you can remove your wiper arm.
Line up your wiper to the tape mark we made on the windshield earlier. Torque to 26 foot-pounds. Line up your wiper to the tape mark we made earlier. Start the nut by hand. Torque the nut to 26 foot-pounds. Reinstall the plastic cap. Close the hood. Remove the tape marks from the windshield. Check for proper operation of your wiper motor.
Thanks for tuning in. We hope this video helped you out. Next time you need parts for your car, please visit 1AAuto.com. Also check out our other helpful how-to and diagnosis videos.
