Hey friends, it's Len here at 1A Auto. Today we're working on our 2001 Ford Focus ZX3 and I want to show you how to do a rear upper control arm. It's going to be very simple. I can do it. You can do it too. If you need this or any other part you can always check us out at 1AAuto.com. Thanks.

Okay, so one of the first things we have to do is take off the wheel obviously. We're going to remove our lug nuts. These are missing the caps. Usually they have a chrome cap on them that would make them 19s. These are actually closer to an 18 so that's what I'm going to use to remove it. But generally speaking, you're going to use a 19 to remove your lug nuts. Leave that one on there a little bit. That's just going to help prevent the wheel from falling off when I take off the last one. Set this aside. Take off our wheel, set it aside.

Here's the arm. We're just going to take it, bring it right into the vehicle, to the approximate area where the old one is. Just make sure it's the same shape. Everything lines up right. Make sure we're dealing with the right beast. This is it. Looks good. Right up here, you've got a mounting bolt. It's a 15 millimeter head. I'm going to use 3/8ths drive because my 1/2 inch drive is a much longer ratchet and I just don't think I can probably get it in there. I'm sure if you used an extension, a universal 15 millimeter socket, air gun could probably figure something out a little quicker here, but I'm not going to worry about that right now. I just want to show you how to get it out of here.

I just threw on an extension with a swivels universal socket gives me a little bit more space to be able to swing my ratchet. It feels like it's in there pretty good. Get that one pretty loose. Let's go ahead and loosen this one up. The whole bolt at this point, it's just kind of threading its way out because this is under tension trying to come this way.

It's our bolt. Just comes right through here. Now that we have that one out, I can come back here, grab this one. That's the inside upper bolt there. Looks like it's about the same as this one, but we won't mix them up. Set that aside. Try to grab this arm out of here. There it is. Easy peasy.

Here we are friends, a quick product comparison for you over here. We have our original upper control arm out of the rear of our 2001 Ford Focus ZX3 hatchback. And over here we have our brand new quality 1A Auto part. Both these parts are created the exact same. They have the same shape, the same mounting bushings. To show you, I'll just line them up real quick. As you can tell, same shape, same mounting bushings. They're the exact same. With that said, I don't see any reason why this wouldn't be a quality part to install onto the vehicle, so I'm going to go ahead and do it. If you need this or any other part, you can always check us out at 1AAuto.com. Thanks.

Okay, so this is how it's going to go inside the vehicle. Just like this. You've got where it swoops down at a sharp angle. Then it comes back up and it just kind of hangs out and comes out this way. The area where it comes up and out is going to be the outer area where it goes here. This area is going to go up and in there. Grab my bolt. Can use thread locker if you'd like, it's your prerogative. For the purpose of this video, I'm not going to worry about it. I'm just going to take my bolt. First. I'm going to get my arm up in there.

Now I'm going to get my bolt through my hole. Just start it in a couple of threads here. Not going to tighten it up or anything. I just want it to be in and the threads so I don't have to worry about stripping anything. Now here comes the hard part. Remember I was telling you that it had pressure. Look at how much, how far away this is and the angle. It's going to be a little difficult. If you happen to have a ratchet strap, it's going to come in handy. Let's give it a try. I just got my ratchet strap set up down along the bottom here. I brought it up through, along here, up around this stud and then down around this way and I'm just kind of using the ratchet strap to pull me in. Grab a pry bar. I'm going to have to resituate it.

Brought it down along the bottom there, up and over across, in between the coil spring here, over the lug nut area, and then just over to this side. And that's just so I can draw this in. Now I just need to get this lined up. See if I can get this to turn a little bit from the other side. Looks like it's close but not close enough.

Get almost. Getting this upper one lined up is just really interesting. Get this bolt so it's turning in there. Once we get it so it's definitely in a few good threads, we'll go ahead and get this ratchet strap out of here. It's definitely in. We'll relieve our ratchet strap. I'm just putting a jack underneath here. I'm trying to bring the suspension up to the point where if this vehicle had its wheel on and it was sitting on the ground, it would have that amount of pressure on the suspension. Sitting at curb height is what you would say. That's it right there. that's as far up as it's going to go because our lift is happy there.

Now I'm just going to go ahead and snug up these bolts and then we'll torque them to 85 foot pounds. We'll go 85 foot pounds. Just going to hit it one more time. All right. And do the inside one. There it is. Hit it one more time. All right, both of those are tight. There we are. Just going to wheel it up my leg. Cool. We've got our lug nuts. We're just going to snug up these lug nuts. There we are. Bring it down, torque them up. Here we go, we're going to torque these down to 94 foot pounds with our torque wrench. Go around again. There we are. Do the same to the other side of the vehicle.

Thanks for watching. Visit 1AAuto.com for quality auto parts, shipped to your door. The place for DIY auto repair. And if you enjoyed this video, please click the subscribe button.

Hey friends, it's Len here at 1A Auto. Today we're working on our 2001 Ford focus ZX3 hatchback and I'm going to be replacing a rear control arm. It's going to be super simple. I can do it. You can do it too. If you need this or any other part, you can always check us out at 1aauto.com. Thanks.

Okay, so one of the first things we have to do is take off the wheel obviously. We're going to remove our lug nuts. These are missing the caps. Usually they have a chrome cap on them. That would make them 19s. These are actually closer to an 18, so that's what I'm going to use to remove it. But generally speaking, you're going to use a 19 to remove your lug nuts. Leave that one on there a little bit.

That's just going to help prevent the wheel from falling off when I take off the last one. Set this aside. Take off our wheel. Set it aside. We've got our rear arm here. This is an alignment adjustment. So what you want to do is just mark this with an area on your frame. Oops, here we go. Now I get two crowns. Cool. Cool. All right. So the reason for this is so that when we're putting it back together and we go to tighten it up, we're going to have this alignment camber adjustment right to where it's supposed to go. All right, so first thing we're going to do is loosen this up. These my 19 backside here, 18 on the side closest to me.

Let's leave that nut on there for now. Just going to move around. See how that changes everything here. This pivots and that's going to angle your wheel. So that's the importance of making your markings. All right, we'll leave that like that. Important to note. I've got pressure right here. It's holding up this arm. All right. Not too much pressure. I'm not, you know, lifting the vehicle up off the lift or anything. But the reason for that is so that when I take this bolt out, if this spring is under any tension, I want to be able to control how fast this arm can come down. So this can't just come flying down, potentially hurt me. We're going to remove this bolt. It has a welded nut on the backside. This is a 15 millimeter.

I'm just going to try to maneuver this so that I'll be able to get this bolt out of here. Maybe up, maybe down. Guess we'll have to see which way it needs to go. Getting a little bit more slack here. Okay. Here's our bolt. Set this aside and we can slowly lower this down. There it is. All right. It's like we still get a little bit of spring tension here. It's the reason for having this here. I can bring it down at my own leisure. I know I'm safe. The springs aint coming flying out. I'm just going to bring the vehicle up a little bit more so it'll relieve a little bit more tension.

Here we are. Let that hang. Here's our rear coil spring. Get this nut off of here. This right here has a slot in it and that slot lines up with that divot on the adjustment washer there, so that way there when you turn this backside of the bolt, it turns that and it does what I showed you before. Let's get this out of here. See if I can get my bolt out and through. Here it is, and here's our rear lower control arm.

I'm just trying to get this rubber off of here. Do whatever you have to do to get it off because we want to switch it over to our new control arm. Here we are. Here it is. The reason why it's so hard is because right along here there's a little lip and that just holds on inside there. Over here we have our lower control arm out of the rear of our 2001 Ford focus ZX3 hatchback. Over here we have our brand new quality 1A Auto part. Both these parts are created the exact same. They've got the same shape as you could tell. Same length, super important. You got your mounting holes, right? And then up here, same. And then of course even the spot for the little rubber jounce bumper there.

This brand new quality, 1A auto part has everything that we need. With that said, I don't see any reason why I wouldn't want to install it into the vehicle. So I'm going to go ahead and do it. If you need this or any other part, you can always check us out at 1aauto.com. Thanks.

So here's our adjustment piece, right? That's the side that I was holding with the wrench. Came through this way and we have our adjustment washer. You can see where it slides into the groove right there. And then we have our neoprene locking nut. Generally speaking, these are reusable. If you felt the need, you could use thread locker on it to make sure, but it should be good to go. So this is the way it's going to go in. Just like this. Just going to go through this sub frame, right through there and hold our lower control arm. Got our control arm, just let me see if I can get this up and in here. There we are. That lines up.

Just going to start this on here. We're not going to tighten this up yet. Let's move ahead to the next step. So right inside the lower area of the control arm there, you can see there's like a little groove, comes around and it stops there. That's where the end of your coil springs is going to rest up against. So you want to make sure when you're installing this, you have the end of your coil spring right up against where that hole is. To be able to confirm it you could just look through the hole once you're starting to get it up in there.

So it looks as though I'm going to go just about right here. So I want to get this ready. I'm going to bring this up and in. Turn it as needed here. Looks like that should be it. See about bringing this over. Cool. I'm going to grab my safety glasses. Super important in case this thing slides out. The arm comes down and the spring wants to come and try to hurt me for some reason, even though I did nothing wrong. Accidents happen.

Before we go too far with that though, I'm going to grab my rubber bushing. I'm just going to see about trying to get the rubber bushing onto the new arm. There it is. And now we'll go up. As we bring this up, whether it's with a floor jack or a bottle jack, whatever it is you're using, it's applying pressure to the spring, trying to compress it. So you need to keep that in mind. If this decides it wants to come out and let this arm down, this spring's going to want to do something kind of crazy. And so just get out of the way if something happens.

Here we are. I'm just going to try to line up my bull hole here. Whatever you got to do to get it lined up. Your situation may be a little different than mine, but that looks pretty great right here. I'm just going to go from the rear of the vehicle towards the front. Lower this down a little bit and see if I can bring that up. Okay.

So right now it's through this part, but this actually needs to come through at an angle like this. So now that we've got it through this side, I'm going to go ahead and lower this down and then I'm going to try to grab just a little bit further over on the forward side of this and see if I can get it to go up at an angle. Right up in here.

Okay. So I got my bolts started in here. I got a couple threads. The way that I did it is, I just kind of jacked up along the side right here so I can tilt the lower control arm's coach to get it to line up with this because it's not sitting parallel to the ground. All right. You could use something like a ratchet strap if you have a ratchet strap or whatever you have to do to make it happen. So to continue, I'm just going to take this, I'm going to bottom it out and then I'm going to go ahead and bottom out the other side. And then we'll torque them down. Before we go too far with bottoming this out, what we're going to do, we're going to bring up the suspension. It's high enough, maybe down a little bit. There we are.

Just bring it up so that way there the suspension's compressed as if the vehicle was sitting on the ground. All right. So it's under load right now. Okay, let's bottomed out. We'll torque that in a minute. We're going to come up here and tighten these. Okay. It's time to start snugging this up. You'll notice that as I turn this back here, I'm moving my marks. Okay, so use your wrench, line up the mark with where you want it and then go ahead and use the ratchet on the rearward side of the bolt or rear side of the car to snug it up once you have it lined up with where you want.

It doesn't need to be perfect, just want it to be close because after you're done this service, you're going to want to bring it down to a reputable shop and go ahead and get an alignment anyways. So this is just going to get a close for the next person that's going to be doing it for you. We've got that snugged up. We've got this snugged up. Let's go ahead and torque them down. We're going to torque this down to 85 foot pounds with our torque wrench. I'm holding the backside.

There we are. I'm going to go ahead and do it one more time. Tight. We'll move along to here. I'm going to switch over to my 15. All right and hit it again. Torqued. Torqued. Get this out of here. Onto the next step. Here we are. Just going to wheel it up my leg. Cool. We've got our lug nuts. We're just going to snug up these lug nuts. There we are. Bring it down, torque them up. Okay, so here we go. We're going to torque these down to 94 foot pounds with our torque wrench. Go around again. There we are. Do the same to the other side of the vehicle.

Thanks for watching. Visit 1aauto.com for quality auto parts shipped to your door, the place for DIY auto repair. And if you enjoyed this video, please click the subscribe button.

Hey, friends. It's Lenny here at 1A Auto. Today we're working on our 2001 Ford Focus. It's the ZX3 model with the hatchback. We're going to be replacing the rear forward lower control arm. It sounds complicated, but it's in the rear of the vehicle. It's the forward lower control arm. It's going to be easy peasy. I can do it. You can do it too.

As always, if you need any parts, you can always check us out at 1aauto.com. Thanks. Okay, so one of the first things we have to do is take off the wheel, obviously. We're going to remove our lug nuts. These are missing the caps. Usually they have a chrome cap on them. That would make them 19s. These are actually closer to an 18 so that's what I'm going to use to remove it, but generally speaking, you're going to use a 19 to remove your lug nuts.

Leave that one on there a little bit. That's just going to help prevent the wheel from falling off when I take off the last one. Set this aside. Take off our wheel, set it to the side. So we're gonna go ahead and do the forward lower control arm. This is kind of like a side to side control arm. It just keeps things from moving around side to side. I'm going to use a 15 millimeter up here and a 15 millimeter back here.

These bolts are screwed into welded nuts so you don't have to worry about holding the back side with your wrench or locking pliers or anything like that. They were nice enough to weld them on there for us. There we are. Oh, yeah. All right, nice and loose. I'm just going to try to wiggle the arm around. There's our bolt, okay? Comes through from the front of the vehicle towards the rear. We'll set this aside. Let me see if I can get the control arm to break free so I can hopefully have an opportunity to get this bolt out.

What happens is, is everything kind of kinks in. So if you have this unbolted right here or the bushings are bad in it or whatever, what you'll notice is is the rear can do this, which you do not want it to do. Okay? So that's the importance of this right here. It's kind of like a stabilizing arm. It's our lower bolt. Put that aside, grab this, pull it right out of here.

So here we are friends, a quick product comparison for you. Over here we have our rear suspension, forward lower control arm out of our 2001 Ford Focus hatchback ZX3. Over here we have our brand new quality 1A Auto part. As you can tell both parts are the exact same. We have the same mounting holes, same shape, same length, super important. They're both the exact same. With that said, I don't see any reason why this wouldn't be a quality part to install into the vehicle. So I'm going to go ahead and do it. If you need this or any other part, you can always check us out at 1aauto.com.

Okay, so we've got our forward lower control arm here. You'll notice that it bubbles out this way and it's inverted this way. The inverted goes towards the rear of the vehicle and the bubbled out portion goes towards the forward end of the vehicle. Put this up in here like that, so it's lined up. You can use some thread locker on these bolts if you'd like to, it's your prerogative. For the purpose of this video I'm not going to worry about it.

Just going to get that in there like that. Okay. Now we've just got to get this lined up. Give this a couple of loving bonks here. That looks pretty great. Okay, so this is pretty close. You can see that the hole in this right here does not line up with the hole in the control arm yet. So what we're going to have to do is we're just going to have to try to pull this this way a little bit. So I'm going to grab my ratchet strap. Get it set up. Okay. We've got this set up. I'm just bringing this over. Let's see the holes lining up here.

Let's see if that's lined up the wrong way. There it is. So it's definitely started. This one's definitely started. Get this off of here. Get our ratchet strap off of here. Now I'm going to put some pressure underneath here and get the vehicle to curb ride height, and then I'll go ahead and snug these up. Now that I've got the suspension compressed, the springs are compressed, the shocks compressed I'm just going to snug these up.

Okay, that's snug. Same thing for this one. Okay, it's bottomed out. Bottomed out. Let's torque them, 85 foot pounds. I've got my torque wrench. Just gonna try it one more time. Tight. All right, we'll hit it one more time. Tight. Tight. On to the next step. Here we are. Just going to wheel it up my leg. Cool. We've got our lug nuts. We're just going to snug up these lug nuts.

There we are. Bring it down, torque them up. Okay, so here we go. We're going to torque these down to 94 foot pounds with our torque wrench. Go around again. There we are. Do the same to the other side of the vehicle.
