Replaces
Part Details
About TRQ:
TRQ is a trusted brand dedicated to making every repair a success story by combining premium parts with easy installation. Each TRQ part is engineered by a team of automotive experts to meet or exceed OEM standards, delivering enhanced performance and maximum longevity. With rigorous in-house testing, the brand ensures superior fit and function across every product line. TRQ also provides customers with best-in-class, step-by-step installation videos—so you can complete repairs with confidence, whether you're a first-time DIYer or an industry professional.
Attention California Customers:
WARNING: This product can expose you to chemicals including Lead and Lead Compounds, which are known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Lifetime Warranty
This item is backed by our limited lifetime warranty. In the event that this item should fail due to manufacturing defects during intended use, we will replace the part free of charge. This warranty covers the cost of the part only.
FREE Shipping is standard on orders shipped to the lower 48 States (Contiguous United States). Standard shipping charges apply to Hawaii and Alaska.
Shipping is not available to a P.O. Box, APO/FPO/DPO addresses, US Territories, or Canada for this item.
Expedited is available on checkout to the United States, excluding Alaska, Hawaii.
Final shipping costs are available at checkout.
Created on:
Tools used
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the rear drum brakes on this 2011 Chevy Silverado 1500. It's the same process on the Sierra 1500 from the same year. We show you how to do this on the passenger side, but you're going to want to do it on the driver's side as well. It's pretty much the same process.
The tools you'll need for this is a jack and jack stands, 22 millimeter socket and ratchet, flat blade screw driver, two vise grip pliers, wire brush, white grease and a torque wrench.
Start out by carefully removing the center cap with a flat blade screw driver. If you don't have the benefit of air tools, start with the vehicle on the ground. Loosen the lug nuts. Then raise, support and secure the vehicle. Then remove the lug nuts, wheel and tire.
With the wheel off, there's one or two of these locking rings. Use pliers or a flat blade screw driver. Twist them. Usually you can break them off and pull them off. If you want, you can try and get them off all the way and then reuse them. If the drum doesn't come off, you can use a long bolt, M10 in size. You can see that there are two holes. Just put the bolt into the drum and tighten it up. It will help you pull the drum right off.
With the drum off, you can check the condition of the shoes. See our rear one's in pretty good shape. Same with our front ones: in pretty good shape. Also, check the condition of the drum itself. Just run your finger on it. Make sure that there are no deep grooves or anything like that.
There are brake tools specifically for this purpose but we're just using a pair of vise grips. Remove the spring. We're going to remove this spring in here. Also, that bracket's going to come out at the same time. Then there's a spring down below to remove. Basically, you just pull the springs forward or backward and pull them out. Using the vise grip pliers, you want to twist these retaining springs. You want to hold the pin on the back of the brakes. Then you can just pull that pin right out. You can pull that brake shoe back and pull your adjuster out of there. Set that aside. Now you want to do it on this side. Put your finger on the back of that pin, twist the retaining spring out, remove the pin, and remove the brake shoe.
To remove this brake shoe, you need to get the e-brake out of there. Using a large flat blade screw driver, just pry that out of that slot.
To reinstall, you don't need two people here, but it definitely helps to have two people. With one of the vise grip pliers, you want to pull out the center of that spring. With the other set, you want to grip further up so that the spring can't come back down. Then you just want to pry that into the slot on that brake shoe.
Around here, you can see these friction points. You want to take a wire brush and clean each of these up. Just apply a little bit of white grease to each one. Now you want to lift your brake shoe up into place. You want to push that pin through the back. Then twist on that retaining spring. We'll fast forward as he does the same thing on the other side.
Now you want to take that adjuster and put that back into place. Push those two brake shoes together to secure it. Take that little adjuster clip and put that back into place. Now you want to feed the spring down behind that brake shoe. You can see it coming out the other side there. You want to hook it on. Using the vise grip pliers, you want to pull the other end of the spring. Clip it on to the other brake shoe. With this spring, do the same thing but up here on these little brackets on the brake shoes. Your lower spring just clips into these two holes. Now, when you go to put the drum back on, if you realize it doesn't fit, as you can see here, it just doesn't fit. What you want to do is take a flat blade screw driver and hold that adjuster clip back. Use that to turn that adjuster right there. That will bring your brake shoes in. After adjusting it, you want it to still have a little bit of resistance as you push that drum on. As you can see, it fits perfectly.
We'll fast forward as he puts the wheel back on, and puts those lug nuts back in to place. Then you want to lower the vehicle and tighten them the rest of the way. You want to torque those lug nuts to 100 foot pounds in a crossing pattern. Put the cap back on and repeat for the other side. After you've done the brake work, get in. Test your pedal and make sure it's nice and firm. Do some slow stops from 5 and 10 miles an hour before road testing your vehicle.
We hope this helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
BKA19943
Pretty nice kit however the drums don't seem to be perfectly round as I'm getting some noticeable rear end brake hopping when coming to a fairly quick stop.
Everything went together well, and shipping was fast
Very happy with delivery time and product
Real happy with my purchase great fit! I love it
Quality replacement parts. Springs seem of high quality. Everything arrived on time and packaged well. I have never been disappointed ordering through 1A Auto.
Loved how easy and helpful it was to order or return items. They match up items for your car the fastest I've seen.
The drum brakes are not round and vibrate when braking. Removed the drums twice to rotate the position. They still vibrate. Factory quality check was probably skipped on these.
5 star parts , 5 star company
The brake drums are premium and the shoes too and the replacement job went great and I have had no problem with these premium parts,
The beef I have with this kit is that the brake hardware is cheap. One of the clips that secures the emergency brake mechanism to the top of the shoe snapped. I used the old one which is better. The small springs that secures each pad to the back hub are cheaply made. They became very distorted once secured. I removed them and used the old ones which are designed much better. The new springs that connect the shoes together aren't of good quality. I used the old springs. There's nothing wrong with the original springs. The new shoes appear to be good. The drums are CNC constructed which fit perfectly. I don't recommend using the new hardware kit except the spring pins.
Thank you for your inquiry! Yes, that is correct.
This will fit a 2009-2013 Chevrolet Silverado 1500 LTZ.
This part will not fit your vehicle, but we may have a part that is listed to fit. Please enter your vehicle's year make and model in the search bar at the top of the page. This will display parts guaranteed to fit your vehicle. Just be sure to verify all of the information shown in the Vehicle Fit tab before ordering.
These parts will not come as being coated.
Yes. They have a slot for the emergency brake cable to attach to.
Yes it does. I just installed these yesterday on that exact description of a truck
We do not have a specific country of origin for the parts at this time.
Yes, this part will fit your vehicle.
Yes, this part will fit the 2012 Chevy Silverado 1500.
Unless u buy a complete kit, totors are normally for one tire, brake pads always are for 2 tires
